Behringer S16 Digital Snake



The BEHRINGER S16 digital snake is an extremely versatile 16 x 8 digital stage box solution with lots of unique features at a price that anyone can afford. Built tough to withstand the rigors of the road S16 only takes up two rack spaces and connects to FOH with a single inexpensive CAT5 cable. Digital mixing has revolutionized so much of the live entertainment production workflow. But one thing that hasn't changed is having to roll out that heavy cumbersome old analog snake. That is until now! The new S16 Digital Snake from BEHRINGER takes the burden out of connecting your FOH (Front of House) console with the talent. The S16 provides 16 fully programmable remotely controllable high-end mic preamps plus 8 analog balanced XLR returns at the stage end and connects to the FOH via a single CAT5 cable without the need for a dedicated router. KLARK TEKNIK a longtime industry leader in the development of high-end digital audio processing provided the SuperMAC technology that made all of this possible & BEHRINGER made it affordable.

Massive Connectivity
When used as part of a complete X32 system two S16 Stage Boxes can be cascaded via the built-in AES50 ports providing connectivity for up to 32 mic/line inputs 16 balanced outputs and the incredibly-affordable POWERPLAY P-16 Personal Monitoring System which can feed up to 48 individual monitor mixers. Also included are two optical ADAT sockets for connecting channels 1-8 and 9-16 to outboard devices a convenient USB port for system updates via your PC plus MIDI I/O for lighting systems and sound module control.

Standalone Snake Mode
Although the S16 was initially designed for use with BEHRINGER'S flagship X32 digital console any mixing board with AES50 networking capability can tap into the S16's powerful feature set. So if you happen to work on an analog mixing board occasionally you could use two pairs of S16 and ADA8000 to form a high-performance lightweight 16 x 16 digital snake all on one CAT5 connection keeping the preamp remote control functionality.


Warranty: 3 Years

  • 16 MIDAS-designed fully programmable mic preamps for audiophile sound quality
  • 8 analog servo-balanced XLR outputs
  • AES50 network ports featuring KLARK TEKNIK’s SuperMAC networking capability for ultra-low jitter and latency
  • Up to 100 m networking capability via CAT-5e cable (not included)
  • Dual AES50 ports for cascading S16 units—no merger or router required
  • Precise LED metering plus 7-segment displays for signal control on stage
  • Phones output assignable to any of the inputs/outputs for on-stage monitoring
  • Connectivity for BEHRINGER's P-16 Personal Monitoring System for In-Ear applications (not included)
  • Dual ADAT outputs for use in splitter mode and stand-alone digital multicore applications
  • MIDI In/Out for bi-directional communication between FOH console and on-stage MIDI devices
  • USB connector for system updates via PC
  • "Planet Earth" switching power supply for maximum flexibility (100 - 240 V~) noise-free audio superior transient response plus low power consumption for energy saving
  • "Built like a tank" yet compact all-steel 2U rack-mount chassis
  • High-quality components and exceptionally rugged construction ensure long life
  • Conceived and designed by BEHRINGER Germany
